NETx Multi Protocol Server
Multi Protocol Gateway, Logic Engine, OPC Server, BACnet/IP Server
The NETx Multi Protocol Server provides powerful integration and advanced automation with the robust core of the NETx BMS Platform. It supports diverse interfaces, including hotel management and door access control, while offering powerful customization through its logic engine and compatibility with OPC DA/UA, BACnet/IP, oBIX, and MQTT.
Components
Main component - communicates with the devices, stores or processes data point values and provides building management functions
User interface for configuring and managing the data points
Windows-based software for creating logic for the core server using graphical programming.
Functions
Exchange and integrate data and information between different protocols and technologies.
The LUA script-based engine includes a graphical tool for programming function blocks, enabling easy customization and automation of system behavior.
Interfaces
Try our software free for 30 days!
Each trial includes full functionality with complete access to all features. After the trial period, a license is required to continue using the software.
Documentation and Training
Documentation and Training
Technical Details
Technical Details
- Data and information are exchanged bidirectionally between different protocols and technologies
- Automatic conversion rules come into effect for different data types
- The integrated logic engine can also be converted manually.
LUA Script based scripting engine
- Contains a graphic tool for programming function blocks (xLogic Editor)
- More control functionality within the field devices or required control functions that are distributed across devices with different technologies
- Logic engine can read and write data points, perform mathematical operations and calculations, send notifications such as e-mails or messages via social media and much more
- Complex control functions such as PID control or drivers for communication protocols can be implemented
- Ready-to-use logic functions are already included
- Creation of virtual data points for user-specific virtual structures - these data points are only available in the server and can be used like physical data points
- Can be installed and executed on any device with a Windows system (from Windows embedded boxes to large Windows server systems, VMWARE, VirtualBox, Hyper-V, ...) or cloud-based environment (Microsoft Azure, ...)
- Hardware requirements depend on: number of data points and the implemented building management functions (number of defined alarms, logic definitions, ...)
- Minimum requirement (without SQL usage): 1.8 GHz Quad-Core, 16GB RAM, 100 GB disk space, Windows 11, Windows Server 2022, Windows Server 2025
- Minimum requirement (with SQL usage): 1.8 GHz Quad-Core, 16GB RAM, 100 GB disk space + additional SQL disk space, high-performance SSD hard disk, Windows 11, Windows Server 2022, Windows Server 2025
- NETx Vision: iOS 12.1 or later / Android 5.1 or later
